DEYE SOLAR HY-BRID MPPT SINGLE  PHASE 220V INVERTER 12 KW DC BATTERY VOLT 40V 60V
10 YEARS WARRANTY
SUN-7.6/8/10/12K-SG02LP1-EU-AM2/AM3
Single Phase Hybrid Inverter | 7.6-12kW  | 2 MPPT | LV Battery Supported
    Colorful touch LCD, IP65 protection degree
    AC couple to retrofit existing solar system
    Max. charging/discharging current of 250A
    6 time periods for battery charging/discharging
    Support storing energy from diesel generator
    Max. 16 pcs parallel for on-grid and off-grid
    operation; Support multiple batteries parallel
echnical Specifications
    SUN-7.6K-SG02LP1-EU-AM2
    SUN-8K-SG02LP1-EU-AM2
    SUN-10K-SG02LP1-EU-AM3
    SUN-12K-SG02LP1-EU-AM3
    Feedback
Model  SUN-7.6K-SG02LP1-EU-AM2  SUN-8K-SG02LP1-EU-AM2  SUN-10K-SG02LP1-EU-AM3  SUN-12K-SG02LP1-EU-AM3
Battery Input Data
Battery Type  Lead-acid or Lithium-ion
Battery Voltage Range(V)  40-60
Max.Charging Current(A)  190  190  220  250
Max.Discharging Current(A)  190  190  220  250
Charging Strategy for Li-ion Battery  Self-adaption to BMS
Number of battery input  1
PV String Input Data
Max. PV Access Power (W)
 15200  16000  20000  24000
Max DC Input Power（W）  12160  12800  16000  19200
Max DC Input Voltage（V）  500
Start-up Voltage（V）  125
MPPT Voltage Range（V）  150-425
Rated DC Input Voltage(V)  370
Max. Operating PV Input Current (A)  26+26  26+26+26
Max. Input Short-Circuit Current (A)  44+44  44+44+44
No.of MPP Trackers/No.of String Per MPP Tracker  2/2+2  3/2+2+2
AC Input/Output Data
Rated AC Input/Output Active Power（W）  7600  8000  10000  12000
Max AC Input/Output Apparent Power （VA）  8360  8800  11000  13200
Peak Power (off-grid)（W）  2 times of rated power,10s
Rated AC Input/Output Current（A）  34.6/33.1  36.4/34.8  45.5/43.5  54.6/52.2
Max AC Input/Output Current（A）  34.6/33.1  36.4/34.8  45.5/43.5  54.6/52.2
Max Continuous AC Passthrough (grid to load)（A）  50  60
Power Factor Adjustment Range  0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range (V)  220/230 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range(Hz)  50/45-55, 60/55-65
Grid Connection Form  L+N+PE
Total Current Harmonic Distortion THDi  <3% (of nominal power)
DC Injection Current  <0.5%ln
Efficiency
Max Efficiency  97.6%
Euro Efficiency  96.5%
MPPT Efficiency  ＞99%
Equipment Protection
Integrated
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection
Surge Protection Level  TYPE II(DC),TYPE II(AC)
Interface
Communication Interface  RS485/RS232/CAN
Monitor Mode
 GPRS/WIFI/Bluetooth/4G/LAN(optional)
General Data
Operating Temperature Range
-40 to +60℃, >45℃ Derating
Permissible Ambient Humidity  0~100%
Permissible Altitude  2000m
Noise  ＜45
Ingress Protection(IP) Rating  IP 65
Inverter Topology  Non-Isolated
Over Voltage Category  OVC II(DC),OVC IV(AC)
Cabinet size（W*H*D）[mm]  420×670×233（Excluding connectors and brackets）
Weight[kg]  35.6
Warranty  5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
Type Of Cooling  Intelligent air cooling
Grid Regulation  VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI 0 21, EN50549-1,
G98, G99, C10-11, UNE217002, NBR16149/NBR16150
Safety EMC/Standard  IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

.............
