DEYE SOLAR HY-BRID MPPT THREE PHASE INVERTER 20 KW DC BATTERY VOLT 160V 800V
10 YEARS WARRANTY

SUN-5/6/8/10/12/15/20/25K-SG01HP3-EU-AM2
Three Phase Hybrid Inverter | 5-25kW | 2 MPPT | HV Battery Supported
    100% unbalanced output
    AC couple to retrofifit existing solar system
    *Max. 10 pcs parallel for on-grid and off-grid
    operation; Support multiple batteries parallel
    Max. charging/discharging current of 50A
    High voltage battery, higher effificiency
    6 time periods for battery charging/discharging
    Support storing energy from diesel generator
....
Technical Specifications
    SUN-6K-SG01HP3-EU-AM2
    SUN-8K-SG01HP3-EU-AM2
    SUN-10K-SG01HP3-EU-AM2
    SUN-12K-SG01HP3-EU-AM2
    SUN-15K-SG01HP3-EU-AM2
    SUN-20K-SG01HP3-EU-AM2
    SUN-25K-SG01HP3-EU-AM2
    Feedback
Model  SUN-5K -SG01HP3-EU-AM2  SUN-6K -SG01HP3-EU-AM2  SUN-8K -SG01HP3-EU-AM2  SUN-10K -SG01HP3-EU-AM2  SUN-12K -SG01HP3-EU-AM2  SUN-15K -SG01HP3-EU-AM2  SUN-20K -SG01HP3-EU-AM2  SUN-25K -SG01HP3-EU-AM2
Battery Input Data
Battery Type  Lithium-ion
Battery Voltage Range(V)  160-700
Max.Charging Current(A)  30  30  37  50
Max.Discharging Current(A)  30  30  37  50
Charging Strategy for Li-ion Battery  Self-adaption to BMS
Number of battery input  1
PV String Input Data
Max. PV Access Power (W)
 10000  12000  16000  20000  24000  30000  40000  50000
Max. PV Input Power (W)  8000  9600  12800  16000  19200  24000  32000  40000
Max. PV Input Voltage (V)  1000
Start-up Voltage（V）  180
MPPT Voltage Range（V）  150-850
Rated DC Input Voltage(V)  600  700
Max Input Short-Circuit Current（A）  30+30  39+30  39+39
Max Operating PV Input Current（A）  20+20  26+20  26+26
No.of MPP Trackers/No.of String Per MPP Tracker  2/1+1  2/2+1  2/2+2
AC Input/Output Data
Rated AC Input/Output Active Power（W）  5000  6000  8000  10000  12000  15000  20000  25000
Max AC Input/Output Apparent Power （VA）  5500  6600  8800  11000  13200  16500  22000  27500
Peak Power (off-grid)（W）  1.5 times of rated power,10s
Rated AC Input/Output Current（A）  7.6/7.3  9.1/8.7  12.2/11.6  15.2/14.5  18.2/17.4  22.8/21.8  30.4/29  37.9/36.3
Max AC Input/Output Current（A）  8.4/8  10/9.6  13.4/12.8  16.7/16  20/19.2  25/24  33.4/31.9  41.7/39.9
Max Continuous AC Passthrough (grid to load)（A）  40  80
Rated Input/Output Voltage/Range(V)  220/380V，230/400V 0.85Un-1.1Un
Grid Connection Form  3L+N+PE
Rated Input/Output Grid Frequency/Range  50Hz/45Hz-55Hz  60Hz/55Hz-65Hz
Power Factor Adjustment Range  0.8 leading to 0.8 lagging
Total Current Harmonic Distortion THDi  <3% (of nominal power)
DC Injection Current  <0.5%ln
Efficiency
Max Efficiency  97.6%
Euro Efficiency  97.0%
MPPT Efficiency  ＞99%
Equipment Protection
Integrated
DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit Protection, DC Component Monitoring, Arc Fault Circuit Interrupter (optional),
Anti-islanding Protection, DC Switch, Insulation Impedance Detection, Residual Current Detection
Surge Protection Level  TYPE II(DC),TYPE II(AC)
Interface
Communication Interface
RS485/RS232/CAN
Monitor Mode
GPRS/WIFI/Bluetooth/4G/LAN(optional)
LCD/LED Display
LCD
General Data
Operating Temperature Range
-40 to +60℃, >45℃ Derating
Permissible Ambient Humidity  0-100%
Permissible Altitude  2000m
Noise  ≤ 55 dB(A)
Ingress Protection(IP) Rating  IP 65
Inverter Topology  Non-Isolated
Over Voltage Category  OVC II(DC),OVC III(AC)
Cabinet size（W*H*D）[mm]  408*638*237（Excluding connectors and brackets）
Weight[kg]  30.5
Warranty
5 Years/10 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
Type Of Cooling  natural cooling  Intelligent air cooling
Grid Regulation
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,OVE-Richtlinie R25, G98, G99, VDE-AR-N 4105
Safety EMC/Standard  IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

.............
